RE505X AX1500 Wi-Fi Range Extender

• Up to 1.5 Gbps Dual Band Wi-Fi: Separates 5 GHz (1200Mbps) and 2.4 GHz (300 Mbps) WiFi bands for faster speeds and greater capacity with the WiFi 6 technology.†

• Smart Roaming: Walk from room to room and stay connected with the fastest possible speeds

• EasyMesh-Compatible: Flexibly creates a Mesh network by connecting to an EasyMesh-compatible router for seamless whole-home coverage.

• Gigabit Ethernet Port: Provides faster wired connections to smart TVs, computers and gaming consoles

• AP Mode: Create a new WiFi access point through the Gigabit Ethernet port to enhance your wired network with WiFi capability.

• Easy Setup: Plug in and then easily set up via a press of the WPS button or via the Tether App.

• Ultimate Compatibility: Extends the range of any Wi-Fi router or wireless access point.

Cutting-Edge Wi-Fi 6

The latest Wi-Fi technology eliminates annoying lag, endless loading, and dead spots. Enjoy the future of faster network loads and more connections.

Fill Every Inch of Your Home with Wi-Fi 6

The 505X wirelessly connects to your router, boosting your Wi-Fi 6 signal throughout your home so you can binge watch your favorite show anywhere.

Built-In Access Point Mode

RE505X is more than just a wireless range extender. Simply plug an Ethernet cable into its port to easily turn that wired connection into a high-speed dual band wireless signal.

Flexibly Create Whole Home Mesh WiFi

RE505X is EasyMesh-compatible. If you have any WiFi dead zones at home, simply add another EasyMesh router to further form your whole home mesh WiFi. No more searching for a stable connection. For a better network experience, we recommend combining with RE505X.

WiFi Dead Zone Killer

Eliminate weak signal areas with WiFi coverage for the whole house

Smart Roaming

Uninterrupted streaming when moving around your home

One WiFi Name

No more switching WiFi network names

Control at Your Fingertips

Set up and manage your Wi-Fi through the TP-Link Tether app from your smartphone (Android, iOS), including TP-Link routers and range extenders.

Hardware Features:

• Interface: 1 Gigabit Ethernet Port
• Button: WPS Button, Reset Button
• Input Power: 100-240V~50/60Hz
• Max Power Consumption: 10W
• Antenna: 2 External Antennas

Wireless Features:

• Wireless Standards: IEEE 802.11a/n/ac/ax 5GHz, IEEE 802.11b/g/n 2.4GHz
• Frequency: 2.4GHz and 5GHz
• Signal Rate: 300 Mbps at 2.4GHz, 1200 Mbps at 5GHz
• Working Modes: Range Extender/Access Point
• Wireless Security: 64/128-bit WEP, WPA/WPA2-PSK encryptions
• Transmission Power: CE (EU): 2.4G＜20dBm, 5G＜30dBm
• Mesh Technology: EasyMesh-Compatible

Reception Sensitivity:

• 5GHz:
• 11a 6Mbps: -93dBm,
• 11a 54Mbps: -75dBm
• 11ac HT20 MCS0: -92dBm,
• 11ac HT20 MCS8: -70dBm
• 11ac HT40 MCS0: -90dBm,
• 11ac HT40 MCS9: -66dBm
• 11ac HT80 MCS0: -87dBm,
• 11ac HT80 MCS9: -62dBm
• 2.4GHz:
• 11g 54Mbps: -77dBm,
• 11n HT20 MCS7: -75dBm
• 11n HT40 MCS7: -72dBm

Wireless Functions:

• Enable/Disable Wireless Radio
• DFS (the latest firmware and hardware version is required)
• Access Control
• LED Control
• Power Schedule
• Wi-Fi Coverage

Other Details:

• Network Services Enabled by Default
• Web Server
• Manage and configure device through web (HTTP/HTTPS)
• Port: 80/443 Protocol: TCP
• DHCP Server
• IP address assignment (DHCP)
• Port: 67
• Protocol: UDP
• App management
• Manage and configure device through app
• Port: 20001 Protocol: TCP
• Port: 20002 Protocol: UDP
• Certification: FCC, RoHS
• System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser

Warranty: 3 Years

Note: Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only.
